Fiscal printer ФР7, firmware ФР09
| Specifications | |
| NEW ! | Yes |
| Docking Station | Yes |
| Tablet holder | 7"-10" |
| Built-in customer display | Alpha-numerical, 2 lines |
| External customer display | option |
| Interfaces | 4хUSB, 2xRS232, Ethernet |
| Cash drawer interface | Yes |
| Fiscal version | Yes |
| Tablet communication | USB, Bluetooth using USB adaptor |
| Data transfer modem | Yes |
| Max. printing speed, mm/sec | 200 |
| Cutter | Auto |
| Cutter Reliability | 1 000 000 |
| Printing method | Thermal |
| Print resolution, dots/mm | 8 |
| Print resolution dots per line | 576 |
| Printing mechanism | Seiko CADP347E-E |
| Thermal printing head reliability, km | 100 |
| Paper for printing | Thermal 0,054 - 0,091 mm |
| Paper width | 80-1 |
| Paper roll max diameter, mm | 60 |
| Paper loading method | Easy |
| Effective printing width, мм | 57,5±0,5 or 79±0,5 |
| Character per line | 34; 47 |
| ESC/POS support | Yes |
| Interfaces | USB |
| Energy source | 24V/2,5A |
| Cash drawer control | Yes, 24V |
| Color | Black |
| Width, mm | 175 |
| Length, mm | 150 |
| Height, mm | 245 |
| Quantity of goods | 9100 |
| Quantity of cashiers | 8 |
| Nubber of symbols for product name | 50 |
| Starting message, lines | 5 |
| Final message, lines | 1 |
| TAX groups positive | 6 |
| TAX groups negative | 6 |
| Additional TAX positive | 5 |
| Additional TAX negative | 5 |
| Operation conditions: - T, °С | -5 … +40 |
| - humidity, %, at +30 °С | 10 to 80 (non-condensing) |
| Storage conditions: - T, °С | -10 ...+50 |
| - humidity, %, при +30 °С | 10 to 90 (non-condensing) |
| Leaflet | Загрузить |
The electronic cash register is designed for operation in the cashier's workplace in retail, hospitality, catering and services. Fiscal register FR7 contains a control strip in electronic form /CTEF/ and meets all the requirements of Ukrainian legislation to the fiscal equipment.
With built-in modem FR7 provides transmission of electronic copies of documents and fiscal checks to the TAX OFFICE. It goes by wired communication channel through information acquirer..
FR7 provides the ability to connect external devices - computer, network equipment, customer display, cash drawer, the USB - device (flash drive, the HID - device, barcode scaner, tablet, etc.) RS-232 socket gives an opportunity to connect scales
Connection the Android tablet with front-office installed, allows you to create a full-fledged cashier's workplace.
Areas of use:
- Minimarkets, retail and wholesale trade
- Shops, boutiques, pharmacies;
- Hotels, motels, guest houses, holiday homes, fitness centers;
- Restaurants, cafes, fast food outlets, bars;
- Other areas of the automation of small business, need to implement economic solutions.
