Thermal Receipt Printer PT58UE
1) Low noise and high stability
2) Easy paper loading
3) Easily use and maintain
4) Support mark paper and continuous paper printing
5) Compatible with many kinds of paper width
6) With cash drawer interface
7) Interfaces USB, Ethernet
| Specifications | |
| Cash drawer interface | RJ11-6P6C socket, 24V |
| Max. printing speed, mm/sec | 200-220 |
| Cutter | no |
| Printing method | Thermal |
| Print resolution, dots/mm | 203DPI, 8 dot/мм |
| Print resolution dots per line | 384 |
| Printing mechanism | 2" |
| Thermal printing head reliability, km | >50 km |
| Paper for printing | 0,056 - 1 мм |
| Paper width | 58 |
| Paper roll max diameter, mm | 80 |
| Paper loading method | Easy loading |
| Effective printing width, мм | 48 |
| ESC/POS support | Yes |
| Character size | 8x16dots, or 12x24dots, 9x17dots |
| Character Set | ASCII 9 × 17,12 × 24 |
| Barcodes printing | UPC-A, UPC-E, EAN-8, EAN13, CODE39, ITF, CODEBAR, CODE128, CODE93 QR-код |
| Images printing | Supports raster bitmap print,size of the bitmap is a 256K |
| Memory | FLASH memory size 4M, NV FLASH 64K in size |
| Interfaces | USB, Ethernet |
| Wireless interfaces | no |
| Sensors | Detection sensor is out of paper, open the paper cover sensor |
| Energy source | 12V, 2A |
| Cash drawer control | Yes |
| Drivers available | Windows (WIN7 / WIN8 / Vista / XP / 2000) UBUNTU 12.04 32/64 UBUNTU 14.04 32/64 |
| Color | Black |
| Width, mm | 170 |
| Length, mm | 120 |
| Height, mm | 130 |
| Weight, kg | 0,600 |
| Operation conditions: - T, °С | -10-- +50 |
| - humidity, %, at +30 °С | 10--95% |
| Storage conditions: - T, °С | -40-- +70 |
PT58EU is a thermal POS printer. It has good printing quality and high stability, which is widely used in POS system, food service industry and many other fields.
Main features
1) Low noise and high stability
2) Easy paper loading
3) Easily use and maintain
4) Support mark paper and continuous paper printing
5) Compatible with many kinds of paper width
6) With cash drawer interface
7) Interfaces-USB, Ethetnet
PT58EU connects other devices via Ethernet or USB port.
Driver software features Windows (WIN7 / WIN8 / Vista / XP / 2000) UBUNTU 12.04 32/64 UBUNTU 14.04 32/64
Main features
1) Low noise and high stability
2) Easy paper loading
3) Easily use and maintain
4) Support mark paper and continuous paper printing
5) Compatible with many kinds of paper width
6) With cash drawer interface
7) Interfaces-USB, Ethetnet
PT58EU connects other devices via Ethernet or USB port.
Driver software features Windows (WIN7 / WIN8 / Vista / XP / 2000) UBUNTU 12.04 32/64 UBUNTU 14.04 32/64
